recordings, but these are not readily available in primary care. For
many patients, assessing the rate at rest and then simply exercising
the patient for one or two minutes can be a useful discriminator
of rate control. Our strategy is to reassess heart rate (minimum
of 30 seconds via precordial auscultation or carotid palpation,
as the radial pulse may underestimate the true rate) after a brisk
walk (corridor, stairs, or on the spot, depending on the individual)
broadly applying the targets as set above.
For patients who remain symptomatic after appropriate drug
therapy, formal rate-control assessment is recommended with
Holter monitoring (useful for correlating symptoms with rate) or
exercise testing.
Drug therapy for rate control
When possible, rate-controlling drugs are generally given once
daily in the morning – medicating predominantly at night can lead
to excess nocturnal bradycardia with suboptimal daytime control.
Beta-blockers
Beta-blockers control the ventricular rate at rest and on exertion,
improve symptoms, and are particularly useful as combination
therapy with digoxin.
41
They have an excellent safety profile, and
are also indicated in the management of co-morbid conditions such
as heart failure and ischaemic heart disease. Additionally, there is
evidence for some ‘rhythm-controlling’ effect,
42
perhaps through
reducing ectopic triggers of AF. On this basis, beta-blockers can be
considered a first-line agent in most patients with AF, regardless of
persistence.
1
Typical drugs include atenolol (25–100 mg once daily) and
bisoprolol (2.5–10 mg once daily). In those with significant systolic
dysfunction, bisoprolol or carvedilol (3.125–25 mg twice daily)
should be up-titrated slowly after introduction, so the patient may
take longer to achieve rate control – a decompensated patient with
rapid AF and heart failure may need careful acute rate control in a
monitored in-patient environment.
Calcium channel blockers
Conduction through the AV-node depends largely on calcium
currents, which may be suppressed by non-dihydropyridine calcium
blockers. These are effective rate controllers, and may be superior
to beta-blockers for rate control during exercise.
43
They are particularly useful in patients with contraindications to,
or intolerant of, beta-blockers. The main side-effects are relative
hypotension, and occasionally ankle swelling. The available agents
are diltiazem (typical AF dose 120–360 mg daily) and verapamil
(120–360 mg daily), both in 1–3 doses depending on formulation.
Diltiazem may also safely be combined with digoxin, a highly
effective combination for rate control at rest and on exercise.
Calcium channel blockers should generally be avoided in patients
with significant systolic heart failure. Verapamil can have potent
negative inotropic effects, and diltiazem has been associated with
poor outcomes in ischaemic heart failure.
44-48
The combination of diltiazem with beta-blockers can achieve
rate control where the combination of either agent with digoxin
is ineffective, although this strategy would usually be initiated
in specialist care because there is a risk of marked bradycardia,
particularly in those with a degree of conduction system disease
(
eg
bundle branch block, or presence of 1st degree heart block in
sinus rhythm).
Digoxin
Although historically the commonest drug used in atrial fibrillation,
the routine use of digoxin for management of AF is no longer
recommended for most patients. This is principally because although
it controls heart rate modestly at rest, it does so poorly on exercise.
However, digoxin is recommended as part of a combination rate-
control strategy for those with significant LV dysfunction,
2
given
its positive inotropic functions and ability to improve heart failure
symptoms, or in elderly, sedentary patients with good renal function
and relatively good rate control at baseline.
Caution should be exercised in those with renal dysfunction or
who are on interacting drugs (
eg
amiodarone, verapamil): digoxin
toxicity can ensue, and high digoxin levels have been associated
with increased mortality in people with heart failure.
49
Furthermore,
digoxin is not advised for most patients who have paroxysmal AF,
as a strategy to control rate during paroxysms should they occur
because the previously listed drugs are more effective and may
reduce frequency of paroxysms and some evidence suggests digoxin
has a pro-arrhythmic effect and encourages persistence of AF.
50
In summary, digoxin should not be used for rate-control
monotherapy, except in sedentary patients.
Pacemakers
Rate control is required at both ends of the spectrum. However,
transient bradycardia
is expected in AF, even when average rates
are controlled, and does not necessarily cause symptoms unless
profound and/or prolonged.
In general, permanent pacing is not indicated unless the patient
has symptomatic bradycardia. If this does occur, in the context of
otherwise appropriate rate control, the patient should be referred
to a cardiologist for consideration of permanent pacemaker
insertion. For permanent AF, single-chamber pacemakers are used.
For paroxysmal AF, the aim for patients with bradycardia during
AF should be maintenance of sinus rhythm. Dual-chamber pacing
may be indicated in the presence of (spontaneous or drug-induced)
sinus node dysfunction associated with nonpermanent AF.
AV node ablation
Patients who require rate control but who remain tachycardic
despite optimal pharmacological treatment, have a further option:
radiofrequency catheter ablation of the AV node
, which achieves
both rate control and regularisation of the ventricular rate.
51
This
necessitates implantation of, and dependency on, a permanent
pacemaker in all cases so is typically reserved for older patients, or
those in whom a pacemaker is already in situ.
This ‘
ablate and pace
’ strategy is generally effective and well
tolerated, with many studies showing an improvement in quality
of life and left ventricular function.
51-53
Some patients experience a
worsening in symptoms after the procedure, especially if there is
underlying ventricular dysfunction, although in some this may be
ameliorated by biventricular pacing. Fibrillation of the atria, and risk
of thromboembolism, both continue.
Rhythm control
The aim of the rhythm-control strategy is to restore and maintain
sinus rhythm. In general, this strategy is far more likely to involve
access to specialist cardiology services. Patients often still require
rate control until sinus rhythm is restored, and during any paroxysms
that break through the control of anti-arrhythmic drugs.
